SLM-5650B Satellite Modem

Revision 2

TRANSEC Module HTTPS Interface 10–16 MN-SLM-5650B

10.4.4 Firmware Info

The firmware page provides firmware status and management capabilities for the TRANSEC

module.

Figure 10-6. Firmware Unit Info Page

10.4.4.1 Firmware Information

Item Description

Security Module

Bootrom Info

Boot Loader version information.

Image 1 Info

Slot 1 firmware image version information.

Image 2 Info

Slot 2 firmware image version information.

Running Image

Indicates the active firmware image.

10.4.4.2 Upload New Firmware

Item Description

Upload New Firmware Click to navigate to the Upload page
