SLM-5650B Satellite Modem
Revision 2
Base Modem HTTP/HTTPS Interface 7–22 MN-SLM-5650B
Table 7-1. Summary of Counters for Port Statistics Pages
Port Attribute Description
FPGA
Total Number of received packets.
Total Number of received packets with FCS Errors.
Rx Frame Errors Total number of received packets with Frame Errors.
Total number of dropped packets.
Total Number of transmitted packets.
TX CRC Total Number of packets with CRC errors.
Total Number of packets with short frames.
TX Long Frames Total Number of packets with long frames.
TX FIFO Full
Total Number of packets dropped because WAN FIFO
was full.
Total Number of dropped packets.
(Ethernet)
LAN
(Traffic port connected
to J12 RJ-45)
WAN
(Traffic port connected
to satellite interface)
Multicast (Out)
The number of packets sent that have a Multicast
destination MAC address.
Broadcast (out)
The number of packets sent that have a Broadcast
destination MAC address.
Unicast (Out)
The number of packets sent that have a Unicast
destination MAC address.
The number of bytes sent
FCS Errors (in)
Total packets received with a CRC error not counted
in Fragments (In), Jabber (In) or Rx Errors (In).
Total packets received with Rx Error signal.
Jabber (in)
Total packets received with length of more than
Maxsize (2048 bytes) but with invalid FCS.
The number of good Flow Control packets received.
Multicast (in)
The number of good packets that have multicast
destination MAC address.
Note: this address not included 802.3 Flow Control
messages counted in Pause (In) or does it included
Broadcast packets counted in Broadcast (in).
Broadcast (in)
The number of good packets received that have a
broadcast destination MAC address.
Unicast (in)
The number of good packets received that have a
Unicast destination MAC address
Total bytes received in bad Ethernet packets.
Total good Ethernet bytes received.
