Network Processor (NP) Interface 8–3 MN-SLM-5650B
8.2.1 Connector Pinout
The LAN interface is comprised of four IEEE 802.3ab 10/100/1000Base-T copper interfaces via four
female RJ-45 connectors wired as shown in Table 8-1.
Table 8-1. LAN Interface Connector Pinout (Typical)
Pin # Description Direction
1
BI_DA+
Bidirectional
2 BI_DA-
3
BI_DB+
4 BI_DC+
5 BI_DC-
6
BI_DB-
7
BI_DD+
8 BI_DD-
