SLM-5650B Satellite Modem

Revision 2

Base Modem HTTP/HTTPS Interface 7–8 MN-SLM-5650B

Admin | SNMP

Chapter 6. ETHERNET-BASED MANAGEMENT

Use this page to set and return administration information for the SLM-5650B Simple Network

Management Protocol (SNMP) feature.

Figure 7-3. Admin | Remote Page

Click [Submit Admin] to save any changes made on this page.
