Comtech EF Data SLM-5650B - IESS-309 Mode - Extended (Closed Network

SLM-5650B Satellite Modem
Revision 2
Appendix B B–10 MN-SLM-5650B
Modulation
Type
Overhead
R-S Code
Word
R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
OQPSK 7/8
IESS-309
219,201
4, 8, 16
64
8448
42.503
5610.385
OQPSK 7/8 IESS-309 194,178 4, 8, 16 64 8448 42.516 5612.112
OQPSK 7/8 IESS-309 225,205 4, 8, 16 64 8448 42.818 5561.624
OQPSK 7/8
IESS-309
208,192
4, 8, 16
64
8448
42.463
5604.181
B.1.6 IESS-309 Mode – Extended (Closed Network)
Modulation
Type
Overhead
R-S Code
Word
R-S Depth
Data Rate (kbps) Symbol Rate (ksps)
Min Max Min Max
BPSK 1/2 None Off N/A 64 15000 128 30000
BPSK 1/2 None 219,201 4, 8, 16 64 13767.123 139.462 29999.999
BPSK 1/2 IESS-309 Off N/A 64 8448 136.533 18022.4
BPSK 1/2
IESS-309
219,201
4, 8, 16
64
8448
148.76
19636.346
BPSK 3/4
None
Off
N/A
64
22500
85.333
29999.999
BPSK 3/4 None 219,201 4, 8, 16 64 20650.684 92.975 29999.999
BPSK 3/4 IESS-309 Off N/A 64 8448 91.022 12014.933
BPSK 3/4 IESS-309 219,201 4, 8, 16 64 8448 99.173 13090.898
QPSK 1/2
None
Off
N/A
64
30000
64
30000
QPSK 1/2 None 219,201 4, 8, 16 64 27534.246 69.371 29999.999
QPSK 1/2 IESS-309 Off N/A 64 8448 68.267 9011.2
QPSK 1/2 IESS-309 219,201 4, 8, 16 64 8448 74.38 9818.173
QPSK 3/4
None
Off
N/A
64
20000
42.666
30000
QPSK 3/4
None
219,201
4, 8, 16
64
41301.369
46.487
29999.999
QPSK 3/4 IESS-309 Off N/A 64 8448 45.511 6007.467
QPSK 3/4 IESS-309 219,201 4,8, 16 64 8448 49.587 6545.449
OQPSK 1/2 None Off N/A 64 30000 64 30000
OQPSK 1/2
None
219,201
4, 8, 16
64
27534.246
69.371
29999.999
OQPSK 1/2 IESS-309 Off N/A 64 8448 68.267 9011.2
OQPSK 1/2 IESS-309 219,201 4, 8, 16 64 8448 74.38 9818.173
OQPSK 3/4 None Off N/A 64 20000 42.666 30000
OQPSK 3/4
None
219,201
4, 8, 16
64
41301.369
46.487
29999.999
OQPSK 3/4 IESS-309 Off N/A 64 8448 45.511 6007.467
OQPSK 3/4 IESS-309 219,201 4, 8, 16 64 8448 49.587 6545.449
