SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–33 MN-SLM-5650B
CONFIG: Remote EthernetConfig Option Card
AddrAddrMode
Use the  arrow keys to select the Address Mode as Single or Dual, and
then press [ENT].
When in Single Address Mode, select Traffic IP to edit the
NP Module’s Ethernet IP Address and Range.
When in Dual Address Mode, select Mgmt IP to edit the NP
Module’s Ethernet IP Address and Range.
CONFIG: Remote EthernetConfig Option Card
AddrSecurity
Use the  arrow keys to select the FAST-enabled Management Security
level as Low or High, and then press [ENT].
CONFIG: Remote EthernetConfig Option Card
AddrBPM
Use the  arrow keys to select the FAST-enabled BPM mode as On or
Off, and then press [ENT].
CONFIG: Remote  EthernetConfig  Option Card Addr
Traffic IP
Ethernet IP Address/Range:
192.168.001.054/24 (E)
When the module is in Single Address Mode, use the  arrow keys to
select the digit to edit, and then use the  arrow keys to edit the value of
that digit. Press [ENT] when done.
CONFIG: Remote  EthernetConfig  Option Card Addr
Mgmt IP
Ethernet IP Address/Range:
192.168.002.072/16 (E)
When the module is in Dual Address Mode, use the  arrow keys to
select the digit to edit, and then use the  arrow keys to edit the value of
that digit. Press [ENT] when done.
