SLM-5650B Satellite Modem
Revision 2
Network Processor (NP) Interface 8–35 MN-SLM-5650B
Item Description / Settings
Management IP
Address
This is the IP Address of the NP Interface only. Once set to a valid value, it is the address
that should be used for management and control connectivity when IP Addressing Mode
was set to Dual.
Management Subnet
Mask
The subnet mask is used in conjunction with the Management IP Address to determine the
subnet locally attached to by the LAN interfaces.
Click [Submit] to save changes made to any of the above items.
VLAN Port Configuration
Item / Selection Description / Settings
Single Port VLAN
Using the drop-down menu, select Single Port as Enabled or Disabled. When Single Port
VLAN is Enabled, the modem’s Ethernet port accepts the VLAN-tagged packets from the
NP Interface port specified in the "VLAN Port Select" drop-down.
VLAN Port Select
Using the drop-down menu, select Port 1 through Port 4 to designate the Ethernet port on
which VLAN-tagged packet are ingress and egress.
VLAN ID
Enter an ID value from 2 to 4095. Packets containing specified VLAN only will ingress and
egress from the NP Interface port specified in the "VLAN Port Select" drop-down.
Click [Submit] to save the desired Single Port VLAN setting.
Proxy ARP Enable
Proxy ARP (Address Resolution Protocol) is a technique by which an NP Interface in Router Mode
on a given network answers the ARP queries for a network address that is not on this network, but
is reachable via the NP Interface.
With Proxy ARP enabled, the NP Interface (in Router Mode) 'snoops' all ARP_REQs; it will send an
ARP_REPLY (one if the ARP_REQ host address is an NP host address that is reachable via one of
the routes in the Route Table).
Using the drop-down menu, set Proxy ARP Enable as Enabled or Disabled.
Click [Submit] to save the desired Proxy ARP Enable setting.
