SLM-5650B Satellite Modem
Revision 2
Appendix C C–49 MN-SLM-5650B
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to
Query
Global
Configuration
(cont)
qqqqqq.qqq = Tx Data Rate same as TDR
rrrr.rrrr = Tx Frequency same as TFQ
s = Tx Framing Mode same as TFM
t = NP Working Mode same as GBM
u = 1st byte of Tx Spread Factor same as TSF
v = NP Secure Mode same as MIS
w = Tx Reed-Solomon state same as TRS
x = Tx Reed-Solomon code word same as TCW
y = Tx Reed-Solomon interleaver depth same as TRD
z = Tx Spectrum Invert same as TSI
A = Tx Scrambler same as TSC
B = Tx Differential Encoder same as TDE
CCC.C = Tx Power Level same as TPL
D = Tx Clock Source same as TCK
E = Tx SCT Reference same as SCT
F = Tx Clock Invert same as TCI
G = Tx Data Invert same as TDI
H = Tx Data Fault same as TDF
I = Tx BPSK Data Ordering same as TBO
J = Tx Carrier State same as TXO
K = Tx Ternary Code same as TTC
LL = expansion bytes
MM.MMM = CnC Freq Offset Range same as CCF
N = Rx FEC Type same as RFT
O = Rx Modulation Type same as RMD
P = Rx Code Rate same as RCR
QQQQQQ.QQQ = Rx Data Rate same as RDR
RRRR.RRRR = Rx Frequency same as RFQ
S = Rx Framing Mode same as RFM
TTT = CnC Re-acq Time same as CRA
G
HHHHHJKLMMM
IIIIIIIIIIIIIIIII
(see Description of
Arguments)
