SLM-5650B Satellite Modem
Revision 2
Front Panel Operation 5–15 MN-SLM-5650B
CONFIG: Tx Spreading
You must first go to the (CONFIG:) MODE submenu and set the modem
type as LDPC in order to select this menu.
Tx Spreading: Factor:0001 Polyn:0 GSN:0000
ChipRate: 000065.881kcps (E)
Use the arrow keys to select Factor or Polyn, and then press [ENT].
Use the arrow keys to select GSN, and then press [ENT].
Use Method 1 or Method 2 to configure these options:
Key in the desired value using the numbered keypad. Press
when done.
2
Select the digit to be edited using the
arrow keys, and then change the value of that
digit by using the arrow keys. Press [ENT] when done.
Note the Following:
Option Setting
Tx Spreading Factor, which is settable from 1 to 512 in integer steps.
Select 0 or 1.
GSN Select 0 to 9999.
