Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera On-Semi Sensor Models • 91
Sensor Gain range
(in the Digital domain)
1 to 16x multiplying factor
1 to 15x multiplying factor
(Applied after Maximum
Analog gain)
1 to 15x multiplying factor
(Applied after Maximum
Analog gain)
1 to 16x multiplying factor
(Applied after Maximum
Analog gain)
Dynamic Range 62.1 dB 75.5 dB 68.3 dB 76.4 dB 56.8 dB
Signal-to-noise 39.8 dB 43.9 dB 43.9 dB 39.6 dB 33.1 dB
Full Well Charge (-e) 10 ke (max) 32ke (max) 32ke (max) 11ke (max) 2.75ke (max)
Pixel Size (µm) 4.8 x 4.8 5.86 x 5.86 5.86 x 5.86 3.45 x 3.45 3.45 x 3.45
**
Excluding the input Opto-coupler’s propagation delay, trigger input jitter time is added to the fixed line count delay as shown by the linked graphic.
† FRM Fast Readout Mode
‡ HSD High Sensitivity Design
