Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 163
Display Name Feature & Values Description
Version
& View
Flat Field Correction Mode flatfieldCorrectionMode Sets the mode for the Flat Field correction. NanoXL
1.06
Beginner
DFNC
Off Off Flat Field Correction is disabled.
Active Active Flat Field Correction is enabled.
Calibration Calibration When this mode is selected, the camera is configured
for flat field correction calibration. The device may
automatically adjust some of its features when
calibrate mode is enabled. The features that are
automatically adjusted are device specific. The device
will not restore these features when the Flat Field
Correction Mode feature is changed from Calibrate
mode to another mode. <Expert>
Flat Field Correction
Current Active Set
flatfieldCorrectionCurrentActiveSet Specifies the current set of Flat Field coefficients to
use. NanoXL
1.06
Beginner
DFNC
Factory Flatfield FactoryFlatfield Sets the factory Flat Field coefficient table as the
current Flat Field.
User Flatfield 1 UserFlatfield1 Sets User Flat Field 1 coefficient table as the current
Flat Field.
Flat Field Correction Type flatfieldCorrectionType Specifies the Flat Field correction type. NanoXL
1.06
Guru
DFNC
Line-Based LineBase Flat field correction is based on a single line of gain
and offset coefficients.
Flat Field Correction
Algorithm
flatfieldCorrectionAlgorithm Specifies the Flat Field correction algorithm to use.
NanoXL
1.06
Guru
DFNC
Method 1 Method1 The following formula is used to calculate the flat field
corrected pixel: newPixelValue[x][y] =
(sensorPixelValue[x][y] – FFCOffset[x][y]) *
FFCGain[x][y]
Flat Field Algorithm Buffer
Format
flatfieldAlgorithmBufferFormat
1.06
Invisible
DFNC
Mono8 Mono8
Flat Field Algorithm Buffer
Width
flatfieldAlgorithmBufferWidth
1.06
Invisible
DFNC
Flat Field Algorithm Buffer
Height
flatfieldAlgorithmBufferHeight
1.06
Invisible
DFNC
Flat Field Algorithm Gain
Max
flatfieldAlgorithmGainMax
1.06
Invisible
DFNC
Flat Field Algorithm Gain
Min
flatfieldAlgorithmGainMin
1.06
Invisible
DFNC
Flat Field Algorithm Gain
Divisor
flatfieldAlgorithmGainDivisor
1.06
Invisible
DFNC
Flat Field Algorithm Gain
Base
flatfieldAlgorithmGainBase
1.06
Invisible
DFNC
Flat Field Algorithm Offset
Max
flatfieldAlgorithmOffsetMax
1.06
Invisible
DFNC
Flat Field Algorithm Offset
Min
flatfieldAlgorithmOffsetMin
1.06
Invisible
DFNC
Flat Field Algorithm Offset
Factor
flatfieldAlgorithmOffsetFactor
1.06
Invisible
DFNC
