216 • Operational Reference Nano Series GigE Vision Camera
Invalid Frame Trigger InvalidFrameTrigger Event sent on control channel when a frame
trigger occurs in an invalid Trigger region.
Therefore the trigger is rejected and no frame
acquisition occurs.
Image Lost ImageLost Event sent on control channel when an image is
lost due to insufficient memory.
Counter 1 End Counter1End Event sent when counter 1 has reached the
counterDuration count. (ver. 1.06)
Line1 Rising Edge Line1RisingEdge The event will be generated when a Rising Edge is
detected on the Line 1. (ver. 1.08)
Line1 Falling Edge Line1FallingEdge The event will be generated when a Falling Edge is
detected on the Line 1. (ver. 1.08)
Line2 Rising Edge Line2RisingEdge The event will be generated when a Rising Edge is
detected on the Line 2.
(ver. 1.08)
Line2 Falling Edge Line2FallingEdge The event will be generated when a Falling Edge is
detected on the Line 2. (ver. 1.08)
Events Overflow eventsOverflow Event sent on control channel when all previous
active events have been disabled because the
camera cannot send them fast enough, generating
in internal message overflow. Required events
must be re-enabled manually.
Event Notification EventNotification Enable Events for the event type selected by the
EventSelector feature.
Expert
Off Off The selected event is disabled.
On On The selected event will generate a software event.
GigEVisionEvent GigEVisionEvent The selected event will generate a software event.
This entry is deprecated.
Using “On” is recommended.
Event Statistic Selector eventStatisticSelector Selects which Event statistic to display. 1.00
Expert
DFNC
Invalid Frame
Trigger
InvalidFrameTrigger Counts the frame trigger occurring in an invalid
Trigger region.
Image Lost ImageLost Image is acquired but lost before it’s been
transferred.
Packet Resend PacketResend Counts the number of individual packets that are
resent.
Packet Resend
Request Dropped
PacketResendRequestDropped Counts the number of packet resend requests
dropped. The camera queues the packet resend
requests until they are processed. There is a limit
to the number of requests that can be queued by
the camera. When a new request is received and
the queue is full, the request is dropped but this
statistic is still incremented.
Ethernet Pause
Frame Received
EthernetPauseFrameReceived Counts the number of Ethernet Pause Frame
received. Feature limited to 65536 events. See
also PAUSE Frame Support for information on
Ethernet Packet size.
Event Statistic Count eventStatisticCount Display the count of the selected Event.
Expert
Event Statistic Count
Reset
eventStatisticCountReset Reset the count of the selected Event.
Expert
PTP Mode ptpMode Specifies the PTP (IEEE-1588: Precision Time
Protocol) operating mode as implemented by the
Genie Nano.
Expert
DFNC
Off Off PTP is disabled on the device.
Automatic Automatic PTP is enabled on the device. The camera can
become a Master or Slave device. The Master
device is automatically determined as per IEEE-
1588.
Slave Slave Device will operate in PTP slave-only mode.
