Datalogic Magellan 8500Xt User Manual

6-12 Magellan
TM
8500Xt Scanner
2. Verify that the display shows a dash and three hyphens (_ - - -).
This is the overweight indication.
NOTE
The scanner/scale may blank (show an under
score and three hyphens)
at any weight greater than its upper weight limit, but
must blank when
the upper weight limit plus 0.051 pounds are set upon the weighing sur-
face.
Decreasing-Load Test
This test ensures that the scanner/scale responds properly when a heavy
object is followed by a significantly smaller object.
1. Place a 30.0-pound load on the scale and v
erify that the display
shows between 29.99 and 30.01 pounds.
NOTE
If the upper weight limit for your scale is set to other than 30 pounds,
begin by placing weight equaling your upper limit setting.
2. Remove enough weights to leave 20 pounds on the scale. Check
that the display shows between 19.99 and 20.01.
3. Remove 8.0 pounds and verify the display reads between 11.995
and 12
.01 pounds.
4. Remove 4.0 pounds and verify the display reads between 7.995
and 8.
005 pounds.
5. Remove another 6.0 pounds from the scale and check that the
scale r
eads 2 lbs.
You have completed the Decreasing Load Test.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
