7-116 Magellan
TM
8500Xt Scanner
RS-232 ACK NAK Retry Count
This feature sets the number of times for the scanner to retry a label trans-
mission under a retry condition.
To set the RS-232 ACK NAK Retry Count:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET RS-232 ACK NAK RETRY COUNT
below. You’ll need to cover any unused barcodes on this and the
f
acing page to ensure that the scanner reads only the barcode you
intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that
represent the desired number. The selectable range is 0-255 resets.
P
ad all single and double digit numbers with leading zeroes to
yield a three-digit entry (000-255).
NOTE
A setting of 255 specifies “retry forever.”
4. The scanner will automatically exit Programming Mode when the
appropriate amount of digits have been scanned.
SET RS-232 ACK NAK RETRY COUNT
