Product Reference Guide 7-181
UPC-A and EAN-13 Decoding Levels
Decoding levels allow the decoder to be set to perform at one of four
selectable levels:
• Very Conservative — Slower scan time, virtually eleminates mis-
reads. The most secure setting.
• Slightly More Aggressive — Faster scanning, more aggressive, yet
minimiz
es misreads.
• Moderately Aggressive — Even faster scanning, even more aggres-
sive.
• Very Aggressive — Fastest scan speed, most aggressive.
CAUTION
Use caution when setting this feature, as the
aggressive settings for this fea-
ture allow a higher potential for misreads.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode representing the desired option on the following
pages. Y
ou’ll need to cover any unused barcodes on facing pages to
ensure that the scanner reads only the barcode you intend to scan.
3. Complete the programming sequence b
y scanning the SWITCH
barcode.
NOTE
It is important to note that the default for this feature is the “Slightly More
Aggressive” setting. For default settings for other features, see
Appendix E.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
