Product Reference Guide 2-11
Liquid Spills and Moisture
Select a checkstand design which allows fluids to flow through, and directs
liquids away from any electronic equipment or storage areas.
Counter Cutout
The most important consideration when planning the counter opening
for the scanner is the operator’s comfortable reaching distance. The ideal,
ergonomically sound installation allows items to be directed within easy
reach, and a scanning area requiring no lifting or special orientation of
items. If you haven’t already read the information at the beginning of this
section titled,
Pre-Installation Considerations, please do so before continu-
ing these instructions.
The symmetrical design of the scanner permits the operator to easily pass
items from one hand to the other while scanning (either from right-to-left
or left-to-right). With the unique 360- scan zone, scanning is accom
-
plished in one fluid motion. The operator simply slides the item from the
conveyor belt or diverter area through the scanning area and passes the
item to the other hand, which in turn bags it or places it on a take-away
conveyor belt. Movement should flow naturally over the surface of the
scanner.
Note that the following guidelines for preparing an existing checkstand to
accept a scanner, or incorporating the unit into a new checkstand design
will not be accurate for all installations. Although these guidelines will suf
-
fice for most standard installations, the installer may need to make adjust-
ments for varying counter heights and thicknesses, support design, or
other checkstand limitations.
Figure 2-5 shows a typical “left-hand-take-away” checkstand design.
Follow these basic steps to install the unit:
1. Select a position for the scanner that offers a smooth product flow
which best accommodates the reaching distance of the average
operator.
2. Cut the opening in the countertop. Select the appropriate draw-
ing from Figure 2-6, or Figure 2-9 for your model.
3. Install the AC/DC Power Supply, the Remote Scale Display cable
and the interface cable(s) observing the following:
To Next Page
