Datalogic Magellan 8500Xt User Manual

Product Reference Guide 7-63
IBM Port 17 Interface Selection
Remember to cover any unused barcodes on this and the facing page to
ensure that the scanner reads only the barcode you intend to scan.
CAUTION
Great care should be taken to select the correct interface
type, since you can
cause damage to the scanner and/or POS terminal by attempting to change
to an incompatible interface. ALWAYS make interface selections with the host
cable DISCONNECTED.
NOTE
Single cable installations require connection at
the POS Terminal (host) port.
The Scale Host port connection is not used for this interface.
INTERFACE TYPE = IBM PORT 17

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
