Datalogic Magellan 8500Xt User Manual

Product Reference Guide 7-87
OEM USB Interface Options
The OEM-USB interface offers specific control over interaction with cer-
tain devices. Options for this feature are as follows:
• FULL host interface support — Accepts scanner and scale config-
uration host commands.
• Compatible with Magellan SL host interface support — Uses
M
agellan SL host interface support.
• Ignore host interface configuration of scanner and scale
—
Ignores all scanner and scale configuration host commands.
NOTE
This feature applies only to the OEM USB
interface. For other IBM inter-
faces, refer to the feature,
IBM Interface Options, earlier in this section.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan your selection from the barcodes below. You’ll need to cover
any unused bar
codes on this and the facing page to ensure that the
scanner reads only the barcode you intend to scan.
3. Complete the programming sequence b
y scanning the SWITCH
barcode.
OEM USB INTERFACE OPTION = FULL HOST INTERFACE SUPPORT

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
