Datalogic Magellan 8500Xt User Manual

A-8 Magellan
TM
8500Xt Scanner
Manual EAS Deactivation Push Button
Using the programming barcodes contained in Chapter 7, Programming,
the button can be configured to operate always, or only function when the
scanner is enabled
.
PRESS
DURATION
FUNCTION COMMENT
Momentary
a
a. For use in Coupled Mode only
Manually initiates EAS
deactivation
Place the item with the EAS tag downstream
b
b. “Downstream” in this case is defined as being the downstream side of the scan window from the direction
of product flow, or scanning direction.
of the hori-
zontal scan window and push the button.
3 Seconds upon
EA
S error
Allows scanner to resume
function despite
EAS sys-
tem failure (non-fatal error)
EAS Failure Mode is indicated
c
c. If the EAS failure corrects itself, blinking will stop and the EAS LED will turn green.
by:
- EAS LED blinks ON/OFF red, scanning disabled.
- FRU Status LED Indicator blinks ‘9’
- Error tone is sounded for one second
Upon pressing the button for 3 seconds, the scanner will
sound 3 high-pitched beeps
, then resume scan function.
The EAS LED and FRU Status LED will continue blinking
as above, but at a slower rate until EAS system function
is restored.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
