7-276 Magellan
TM
8500Xt Scanner
Standard 2 of 5 Length 2
If Standard 2 of 5 Length Control is set to Fixed-Length decoding, this
feature specifies Standard 2 of 5 second fixed length. If Standard 2of 5
Length Control is set to Variable-Length decoding, this feature specifies
the maximum label length.
NOTE
When in Fixed Length mode, if Length 2
is set to the value of 00 (zero),
then only Length 1 will apply.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET STANDARD 2 OF 5 LENGTH 2 below.
You’ll need to cover any unused barcodes on this and the facing page
to ensur
e that the scanner reads only the barcode you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. The selectable range for this option is
1 to 50. P
ad all single digit numbers with a leading zero to yield a
two-digit entry (01-50).
4. Complete the programming sequence b
y scanning the SWITCH
barcode.
SET STANDARD 2 OF 5 LENGTH 2
