7-106 Magellan
TM
8500Xt Scanner
RS-232 TTL Invert
Enables/disables inversion of TTL.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode below which repr
esents the desired setting for
this feature. You’ll need to cover any unused barcodes on this and
the facing page to ensure that the scanner reads only the barcode
you intend to scan.
3. Complete the programming seque
nce by scanning the SWITCH
barcode.
RS-232 TTL INVERT = DISABLE
RS-232 TTL INVERT = ENABLE
