Product Reference Guide 1-9
Figure 1-4. Environmental Specifications
Operation
Storage
+40 C +104 F
10 C 50 F
Temperature
10 to +40 C
50 to +104 F
Dust Resistant Optics Cavity, IP5X
+70 C +158 F
-40 C -40 F
Temperature
-40 to +70 C
-40 to +158 F
Illumination
Artificial Light:
0-450 Foot-candles
(4,842 LUX)
Sunlight:
0-8,000 Foot-candles
(86,080 LUX)
POS Scanner
Humidity
Hot / Wet 40°C / 95% RH
Hot / Dry 40°C / 5% RH
Cold / Dry 10°C / 5% RH
Warm / Wet 25%C / 50% RH
Spill Proof
(Datalogic MS-0006-13-0004)
Electrical Specifications
Before installation, always verify that the site’s electrical service meets the
scanning-scale’s requirements. The scanner has been engineered for com-
patibility with most international electrical systems operating in ranges
fr
om 100 to 240VAC at 50-60 Hz. Verify that the power source will sup-
ply “clean” electrical power to the equipment; that is, it must be free of
ex
cess electrical noise.
Check the IEC power cord shipped with the scanning-scale. If the cord
will not plug
into your AC power receptacle, the power cord shipped is
not compatible with your electrical system. Please contact your distributor
immediately to receive the necessary information and components to
ensure electrical compatibility.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
