Datalogic Magellan 8500Xt User Manual

Product Reference Guide F-11
5-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E2'.
• Length of supplemental data including prefix must be 8. Total
r
equired length is 24 for EAN-13 and 19 for EAN-8.
• Examples: addon portion is highlighted data is underlined.
UPC-A 5-Digit addon ']E00060992011187]E212345'
UPC-E 5-Digit addon ']E00000000998875]E2
12345'
EAN-8 5-Digit addon ']E400210126]E2
12345'
EAN-13 5-Digit addon ']E01101234567891]E2
12345'
Code 128 Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']C0'.
• length of Supplemental data including prefix is variable but must
be at least
9.
• Examples: addon portion is highlighted data is underlined.
UPC-A Code 128 addon ']E00060992011187]C08100000951'
UPC-E Code 128 addon 'E00000000998875]C
08100000951'
EAN-8 Code 128 addon ']E400210126]C0
8100000951'
EAN-13 Code 128 addon ']E01101234567891]C
08100000951'
Bookland
• The 'Bookland' / ISBN code will be formatted as a vendor spe-
cific AIM label.
• Prefix must be ASCII characters ']X0'.
• length of label data including prefix is 13.
• Examples: ']X01234567890'.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
