Product Reference Guide 6-17
Increasing- Load Test (Phase 3)
After completing the Shift Test, you must complete the Increasing Load
Test using 10.00, 12.50 and 15 kilograms of weight.
NOTE
The upper limit of the scale is configurable accor
ding to POS interface type and may not neces-
sarily be set at 15 kilograms, which is the standar
d setting. For this test, continue to place
weights in 2.50 kilograms increments only to the upper weight limit set for your scale.
1. Place 10.00 kilograms in the center of the weighing surface and
check that the Remote
Display reads between 9.990 kg and 10.010 kg.
2. Place an additional 2.50 kilograms in the center of the weighing
sur
face and check that the display reads between 12.490 kg and
12.510 kg.
3. Place an additional 2.50 kilograms in the center of the weighing
sur
face and check that the display reads between 14.990 kg and
15.010 kg.
4. Remove the weights and verify that the display reads 0.000 kg.
You have completed Phase 4 of the Increasing Load Test.
Blanking Test
This test ensures that the scanner/scale will indicate its weighing capability
has been exceeded if a weight greater than 0.82 kilograms over its maxi-
mum upper weight limit is placed upon the scale platter
.
1. Place weights that total the upper limit plus 0.82 kilograms on
the w
eigh platter. For example: If the upper limit is set at 15 kilo-
grams, place weight totaling 15.82 kilograms.
