Datalogic Magellan 8500Xt

B-10 Magellan
TM
8500Xt Scanner
EAS Interlock Connector — Checkpoint
NOTE
Antenna Connections. Connect ONLY using
approved cables approved by
the manufacturer for this product.
Connector Hardware
RJ-4
Cable Pinout
Table B-9
PIN # SIGNAL
1 GND
2 +5V Out
3 EAS Out
4
Speaker Out
a
a. The “Speaker Out” line is an analog signal (5Vpp
max), connected to one of the internal speaker termi-
nals, intended to connect to an external amplifier to
dr
ive an external speaker.
