Datalogic Magellan 8500Xt User Manual

Product Reference Guide 2-31
Model 960RD: Placing and Installing the Remote Scale Display
(Short Pedestal Base ONLY)
1. Determine where you want to install the Remote Scale Display
based on your counter design, the viewing angle and lighting con-
siderations discussed previously. Reference
Figure 2-16 for the dis-
play’s physical dimensions.
2. Use the short pedestal base template provided in
Figure 2-18 to
mark locations of the mounting screw and cable routing holes.
The
mounting screw holes are on 3
3
/8” (8.57 cm) centers.
NOTE
Before drilling, ensure the holes in y
our base match with the holes indi-
cated on the template.
3. The cable can either be routed through a
3
/4” (19 mm) diameter
hole directly under the mounting base or through the cutout in
the back of the base (see
Figure 2-20).
4. Drill the mounting screw holes using a drill bit of the appropriate
diameter for y
our mounting screws or bolts.
5. Drill the cable routing hole using a
3
/4” (19 mm) drill bit
(optional).
It may be necessary to shorten the stalk that suppor
ts the display head so
that the display is installed at eye level.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
