to allow
visual verification of display function.
If the diagnostics routine is not completed successfully, the scanner will
sound a series of
tones and the Remote Display will show an error code.
Turn to
Chapter 4, Problem Isolation for a description of error codes.
Press the Scale Zero Push Button once more to reset the unit and exit
Sc
ale Diagnostic Mode. See the topic,
Scanner and Scale Reset in Chapter
3 for more information about unit resets.
Cables & Connections
Considerations when routing the power and interface cables for the scan-
ner and scanning-scale are:
• Ensure that cables are not pinched, kinked or pierced.
• Do not route interface cables in close proximity to electrical
motors or
other sources of electromagnetic interference.
• Cables can drop directly from their connectors on
the scanner, or,
alternatively, can be routed along the scanner’s side to the back
(see
Figure 2-13).
Do not plug the AC power cord into the outlet at this time. It is a good
prac
tice to always connect the power cable to the scanner first before plug-
ging it into the AC receptacle. The procedures titled, Set-Up, provided
later
in this section will instruct you to connect the power cord at that
time.
Figure 2-13 illustrates the basic cable routing scheme.
