Product Reference Guide 7-275
Standard 2 of 5 Length 1
If Standard 2 of 5 Length Control is set to Fixed-Length decoding, this
feature specifies Standard 2 of 5 first fixed length. If Standard 2of 5
Length Control is set to Variable-Length decoding, this feature specifies
the minimum label length.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET STANDARD 2 OF 5 LENGTH 1 below.
You’ll need to cover any unused barcodes on this and the facing page
to ensur
e that the scanner reads only the barcode you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. The selectable range for this option is
1 to 50. P
ad all single digit numbers with a leading zero to yield a
two-digit entry (01-50).
4. Complete the programming sequence b
y scanning the SWITCH
barcode.
SET STANDARD 2 OF 5 LENGTH 1

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
