• Example: ']E00060992011187'.
UPC-E
• AIM does not specify UPC-E as a separate symbology using this
transmission format - labels will be transmitted as EAN-13.
• Example: ']E00000000998875'.
EAN-13
• Check digit must be included in label data and is assumed to be
correct.
• Prefix must be ASCII characters ']E0'- total length including pre-
fix must be 16.
• Example: ']E01101234567891'.
EAN-8
• Check digit must be included in label data and is assumed to be
correct.
• Prefix must be ASCII characters ']E4' - total length including pre-
fix must be 11.
• Example: ']E400210126'.
2-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E1'.
• length of Supplemental data including prefix must be 5. Total
r
equired length is 21 for EAN-13 and 16 for EAN-8.
• Examples: addon portion is highlighted data is underlined.
UPC-A 2-Digit addon ']E00060992011187]E112'
UPC-E 2-Digit addon ']E00000000998875]E1
12'
EAN-8 2-Digit addon ']E400210126]E1
12'
EAN-13 2-Digit addon ']E01101234567891]E1
12'
