Datalogic Magellan 8500Xt User Manual

Product Reference Guide 3-7
Error Reporting
If a fatal error is detected during Selftest or operation, the unit will not
advance to Normal Operation Mode. Selftest diagnostics will cause the
unit to sound a long, low tone and/or display an error message on the 7-
segment display indicating where the failure occurred. These messages are
coded to assist the repair technician in identifying the failed component.
If the error is with the EAS deactivation system, the bottom-most LED
will flash red. If an error is indicated, make note of it and contact your
supervisor or technical support representative. A table containing descrip-
tions of these error codes is included in
Chapter 4, Problem Isolation.
If a non-fatal
1
error is detected (such as the loss of one of the two lasers, or
EAS deactivation system error), the unit will sound a long, low tone and
display
a number on the 7-segment display. The unit will advance to Nor-
mal Operating Mode, but performance may be
affected until a correction
or repair is made.
Operational Configuration
Once Selftest diagnostics have been successfully run, a tone is emitted (if
configured to do so, and the unit enters an operational configuration state.
The scanner or scanner/scale will automatically load your specific interface
settings which are required to communicate with the host system. There
are two conditions that must be met before the unit can enter Operating
Mode:
• No barcode label can be in the scan volume while the unit is in
this
state. Progress is halted until the label has been removed,
thereby ensuring that no extraneous barcode data is send to the
host.
• If your scanner has a scale, the scale cannot be in motion (usually
caused
by excessive vibration in the checkstand) for this test to
succeed. A “Scale in Motion” status will be indicated by display-
ing a period and the applicable w
eight unit (lb
. lb
or
kg
. kg
) that is selected.
• The scale must be able to “capture” zero weight. The
display will be seen if there is a weight on the platter
1. Scanner behavior under non-fatal error conditions is configurable. See Chapter 7, Pro-
gramming
for more details.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
