Datalogic Magellan 8500Xt User Manual

Product Reference Guide 4-3
Error Codes
If an error is detected, the scanner will sound a long low tone (for three
seconds) and alternately flash its LEDs, indicating a failure. When this
occurs, press the Volume/Tone Push button to display the error code on
the 7-segment display (refer to
Figure 4-1). If it is configured to do so, the
scanner will also sound a series of b
eeps corresponding to the error code.
The table below describes what these codes mean and what action should
be taken for each.
When troubleshooting, always remember to check all cable connections
first before proceeding with other problem isolation steps.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
