Table 4-1. Error Codes and Corrective Action
Error
Co
de
Probable Cause Corrective Action
0
Blinking
Configuration
No POS interface has been selected (Null interface). See
Chapter 7,
"Interface Type"
to select the required interface using programming
barcodes.
1 Configuration Error
See
Chapter 7, Programming, for details about configuring the scan-
ner using programming barcodes.
2 Interface Board Unplug unit and call technical support personnel.
3 Motor Unplug unit and call technical support personnel.
4
Horizontal Laser
a
a. If only one laser is non-functional, the scanner may continue to work (this is a configurable feature);
however, the 7-segment display will show the error code indicating the failed laser. If both lasers have
failed, the 7-segment display will display either a 4 or a 5, and the scanner will cease to function until
serviced. No alternate blinking of lamps will occur if only one laser has failed.
Call technical support personnel.
5
Vertical Laser
a
Call technical support personnel.
6 Digital Board Unplug unit and call technical support personnel.
7 Scale
See the topic
Scale Error Reporting in this section for problem identi-
fication and corrective actions.
8 Remote Display
Connect the Remote Display. If necessar
y, replace display or cable.
Alternatively, you can disable the Remote Display using the program-
ming procedures described in
Chapter 7.
9 EAS Error
No EAS communication. Check EAS cable connections. Call technical
support personnel.
A Button Module Call technical support personnel.
b Hardware ID
Call technical support personnel.
c Scale Calibration Proceed to scale calibration procedure.
E CPLD ID Call technical support personnel.
Decimal
Po
int
3.3 V Present If not lit, call technical support personnel.
