Datalogic Magellan 8500Xt User Manual

Product Reference Guide 7-273
Standard 2 of 5 Label ID
This feature specifies an Standard 2 of 5 label ID to be added to barcode
data.
NOTE
The programming feature, RS-232 Label ID Control, designates
whether the Label ID is transmitted as a prefix or
suffix or if Label ID is
disabled.
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET STANDARD 2 of 5 LABEL ID below. You’ll
need to cover any unused barcodes on this
and the facing page to
ensure the scanner reads only the barcode you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired Label ID characters; entered as two hex pairs. A
table con
taining the ASCII Character Set and their corresponding
Hex Values is available in the inside back cover of this manual.
ASCII p
arameters must be input by scanning a pair of hexadecimal
digits for each character. Thus, to set a two-character value of AB,
barcodes containing the digits ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned.
The selectable range for this option is any hex value from 00 to FF.
4. Complete the programming sequence b
y scanning the SWITCH
barcode.
SET STANDARD 2 of 5 LABEL ID

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
