Datalogic Magellan 8500Xt User Manual

7-56 Magellan
TM
8500Xt Scanner
Interface Related Features
Interface Type
Specifies the current scanner interface. Selections are:
INTERFACE (I/F) TYPE
I/F I.D. NUMBER
a
a. To access a scanner’s interface identification number, place the scanner in Scanner Diagnostic Mode
and view the 7-segment FRU display (reference
Chapter 2, Diagnostic Modes, for more information).
INTERFACE (I/F) TYPE
I/F I.D. NUMBER
a
RS-232 Standard 05 Keyboard Wedge A 25
RS-232 Wincor-Nixdorf 12 Keyboard Wedge B 26
RS-232 Single Cable 20 Keyboard Wedge C 27
OEM USB 45 Keyboard Wedge D 28
IBM
Port 17
04 Keyboard Wedge E 29
IBM
Port 5B
08 Keyboard Wedge F 2A
IBM
Port 9B
23 Keyboard Wedge G 31
USB Keyboard 35 Keyboard Wedge H 32
Keyboard Wedge I 33
NOT USER-SELECTABLE Keyboard Wedge J 34
Null Interface
7-segment FRU dis-
play indicates 0 at
star
t-up (accompa-
nied by trill beep for
appro
x. 2 seconds)

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
