7-212 Magellan
TM
8500Xt Scanner
Code 39 Length 2
If Code 39 Length Control is set to Fixed-Length decoding, this feature
specifies Code 39 second fixed length. If Code 39 Length Control is set to
Variable-Length decoding, this feature specifies the maximum label
length.
NOTE
When in Fixed Length mode, if Length 2 is set to the v
alue of 00, then
only Length 1 will apply
To set this feature:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET CODE 39 LENGTH 2 below. You’ll need
to cover any unused barcodes on this and the facing page to
en
sure that the scanner reads only the barcode you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that
represent the desired label length. The selectable range for this
option is 00, no
second fixed length, or 01 to 50. Pad all single
digit numbers with a leading zero to yield a two-digit entry (00-
50).
4. Complete the programming seque
nce by scanning the SWITCH
barcode.
SET CODE 39 LENGTH 2
