Datalogic Magellan 8500Xt User Manual

Product Reference Guide A-9
Scale Zero Push Button
The Scale Zero Push Button is used for multiple functions as listed in
Table 1-4.
NOTE
The Scale Zero Push Button has n
o function in a “scanner only”
model.
Table 1-4. Scale Zero Push Button Functions
PRESS
D
URATION
FUNCTION COMMENT
Momentary Zero Scale
When programmed to do so, the yellow LED should be lit when no
w
eight is on the scale, indicating scale at zero. If it is not, press the
switch to zero the scale. The unit will sound a “click” upon pressing
the button.
4 Seconds
Scale Diagnostics
Mode
a
a. Diagnostics Mode is meant for use by trained systems support personnel. Users should not need to ini-
tiate this function under nor
mal circumstances.
This mode allows system support personnel to troubleshoot prob-
lems with the scale. Momentarily press the Scale Zero Push Button
or cycle po
wer to exit Scale Diagnostics Mode.
8 Seconds Resets Scanner Only system support personnel

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
