Product Reference Guide B-3
RS-232 Cable Pinout — continued
Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table 2-2RS-232 Scale Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 +5V pullup +5V pullup
2 CTS IN Clear To Send (input)
3 N/C No Connection
4 RTS OUT Request T
o Send (output)
5 RxD IN Receive Data (Input)
6 TxD OUT Transmit Data (output)
7 N/C No Connection
8 N/C No Connection
9 Gnd Signal Ground
10 N/C No Connection
