Datalogic Magellan 8500Xt User Manual

Product Reference Guide 1-3
How to Use This Manual
You’ll find it helpful to familiarize yourself with the first section of this
manual, since it provides both a general description of the product’s fea-
tures and an overview of the manual’s contents and organization. Refer-
ence the other sections as required for
information about scanner or
scanning-scale installation, operation, maintenance, calibration and bar-
code programming.
Manual Conventions
‘NOTE’ blocks contain information that is helpful
and recommended. They provide information that
is critical to operations and/or procedures
described in this manual.
LEGAL NOTE
‘LEGAL NOTE’ blocks indicate procedures or
activities which may be regulated under law by
governmental agencies. It is your responsibility to
ensure compliance with the regulations that gov-
ern installation of weighing devices.
‘CAUTION’ blocks inform you that proper handling
(adherence to the procedures described) is
required to avoid damage to equipment and/or
property.
‘WARNING’ blocks alert you to potential physical
harm or injury. These statements do not include
potentially fatal hazards, which would be desig-
nated as ‘DANGER’ blocks. Use of this product
does not warrant the need f
or a DANGER block.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
