Product Reference Guide 7-113
RS-232 NAK Character
This feature specifies which ASCII character will be used as a NAK char-
acter.
NOTE
DO NOT set this feature to use previous
ly defined characters such as XON,
XOFF or host commands as this will conflict with normal operation of these
characters. 8-bit data is not recognized when the feature, RS-232 Number
of Data Bits, is set to 7 data bits.
To specify the RS-232 NAK Character:
1. Scan the SWITCH barcode.
2. Scan the barcode, SET RS-232 NAK Character below. You’ll need
to cover any unused barcodes on this and the facing page to
en
sure the scanner reads only the barcode you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that
represent the hex designation for the desired character. A table
contai
ning the ASCII Character Set and their corresponding Hex
Values is available in the inside back cover of this manual. ASCII
par
ameters must be input by scanning a pair of hexadecimal dig-
its for the desired character. For example, if ASCII “A” were the
desir
ed NAK character, you would scan the digits “4”, then “1”
(the ASCII corresponding hex value).
4. The scanner will automatically exit Programming Mode when the
appr
opriate amount of digits/characters have been scanned.
SET RS-232 NAK Character

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
