Datalogic Magellan 8500Xt

2-30 Magellan
TM
8500Xt Scanner
Figure 2-17. Model 8300RD Remote Scale Display Mounting
48 - 60"
(122 - 152cm)
36"
(91cm)
11.5"
(29cm)
24"
(61cm)
Mounting
Example
(optional
cab le
routing)
Dual Display
Heads
Single
Display
Head
Figure 2-18. Model 8300RD Remote Scale Display Mounting Template
25.5mm
85.1mm
116.39mm
41.99mm
