Datalogic Magellan 8500Xt

E-2 Magellan
TM
8500Xt Scanner
Scale Enforced Zero
Return
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Scale Interface Type
4 (RS-232
SASI)
4 (RS-232
SASI)
4 (RS-232
SASI)
7 (RS-232
single
cable)
1 (IBM
Port 17)
3
(OEM
USB)
Remote Display —
Enable/Disable
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
Aux Port Mode 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Laser Failure Mode
0 (single
OK)
0 (single
OK)
0 (single
OK)
0 (single
OK)
0 (single
OK)
0 (single
OK)
Productivity Index
Reporting (PIR)/
Cashier Training (CT)
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
EAS Mode 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
EAS Beep Duration 8 (80ms) 8 (80ms) 8 (80ms) 8 (80ms) 8 (80ms) 8 (80ms)
EAS Retry Count 3 3 3 3 3 3
Manual EAS Deacti-
vation Push Button
2 (enable
only when
scanner
enabled)
2 (enable
only when
scanner
enabled)
2 (enable
only when
scanner
enabled)
2 (enable
only when
scanner
enabled)
2 (enable
only when
scanner
enabled)
2 (enable
only when
scanner
enabled)
EAS Deactivation
Duration — Coupled
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
EAS Deactivation
Duration — Retry
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
50
(500ms)
EAS Deactivation
Duration — Manual
100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec) 100 (5sec)
EAS Active State
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
0 (active
low)
EAS Timeout 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms) 2 (20ms)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 OEM USB
