Datalogic Magellan 8500Xt User Manual

F-14 Magellan
TM
8500Xt Scanner
• If EAN-128 Symbology is Enabled and prefix is ']C1', label will
be identified as an EAN128 otherwise it is identified as a Code
128.
• A prefix of ']C0' designates that no function code is present in the
1st or 2nd character position.
• A prefix of ']C2' designates that a function code 1 is present in
the 2nd character.
• Example : ']C0Code_128.Test'.
PDF417
•Prefix must be an ASCII characters ']L0'.
• Label length excluding prefix character cannot exceed 300 charac-
ters. In addition to this, label length excluding prefix character must
meet requirements imposed by the main scanner’s fixed or variable
label length control for this symbology type.
• Example : ']L0pdf_test_label'.

Datalogic Magellan 8500Xt Specifications

General

Type	Built-in bar code reader
Sensor type	-
Read rate (max)	6400 reads/s
Yaw reading angle	0 - 360 °
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232
Connectivity technology	Wired
Input voltage	100 - 250 V
Input frequency	50 Hz
Power source type	AC
Power consumption (typical)	9 W
Product color	Grey, Silver
Sustainability certificates	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	127 mm
Width	292 mm
Height	178 mm
Weight	- g
