14 Instructions for Use Fabius MRI SW 3.n
For Your Safety and that of Your Patients
CAUTION
Risk of physical injury
To avoid physical injury, pay special attention to
edges, moving parts and corners when working
with
drawers,
the ventilator module,
the writing tray,
swivel arms for mounted devices,
gas cylinders,
vaporizer units,
CLIC absorbers and CLIC adapters,
as well as other accessories.
CAUTION
Fabius MRI is intended to be used on 120 V /
60 Hz supplies in the USA. The corresponding
power cable is listed in the list of accessories.
Connection of Fabius MRI to a 240 V / 60 Hz sup-
ply is only allowed if it is a center-tapped-single-
phase circuit and the power cable is a certified,
hospital-grade cable 10 A/ 250 V AC of max. 3 m
(9.8 ft) length with:
a NEMA 6-15 HG plug,
a SJT 3*18 AWG cable and
a C13 connector.
In this case Dräger recommends the mains cable
with part no. 1868152.
NOTE
Software must be installed by qualified personnel.
We recommend to contact DrägerService for soft-
ware installation.
NOTE
If the correct functionality of the protective earthing
conductor or its connection to the device is doubt-
ful, the device must be operated using the internal
power supply (battery).
