Emerson PACSystems RSTi-EP

User Manual Section 3
GFK-2958L May 2021
Configuration 43
Product
Part No.
Parameter
Optional values
Default value
Channel
Frequency
Measurement,
100 kHz
EP-5212
Ch 0 ... Ch 1: Input filter
5μs [187 kHz] (0) /
11μs [94 kHz] (1) /
21μs [47 kHz] (2) /
43μs [23 kHz] (3) /
83μs [12 kHz] (4) /
167μs [6 kHz] (5) /
333μs [3 kHz] (6) /
667μs [1.5 kHz] (7) /
1ms [732 Hz] (8) /
3ms [366 Hz] (9) /
5ms [183 Hz] (10) /
11ms [92 Hz] (11) /
22ms [46 Hz] (12) /
43ms [23 Hz] (13) /
91ms [11 Hz] (14) /
167ms [6 Hz] (15) /
333ms [3 Hz] (16)
5μs [187 kHz]
2 Channels PWM
Output, Positive
Logic, 24Vdc,
0.5A
EP-5422
Ch 0 … Ch 1: Period
duration = n*20,83ns
1,202 ... 8,388,607
1,202
2 Channels PWM
Output, Positive
Logic, 24Vdc, 2A
EP-5442
IO-Link
Communication
module, 4
Channels
EP-5324
Operating mode
disabled / DO / DI / IO-Link
disabled
Port Cycle
Free running / Fixed cycle /
Message sync
Free running
Port Cycle time [n x 0.1 ms]
4 … 1326
4
IO-Link device check
disabled / type compare /
identical
disabled
DS activation state
disabled / enabled / Clear
disabled
Channel diagnostics
disabled/ enabled
disabled
Process data length input
0 Byte / 1 Byte / 2 Byte / … / 32
Byte / auto
auto
Process data length output
0 Byte / 1 Byte / 2 Byte / … / 32
Byte / auto
auto
Analog Input,
4 Channels
Voltage/ Current
16 Bits
2-, 3-, or 4-Wire
EP-3164
Frequency suppression
disabled (0) /
50 Hz (1) /
60 Hz (2) /
Average over 16 values (3)
disabled
Ch 0 … Ch 3: Measurement
range
0 to 20 mA (0) /
4 to 20 mA (1) /
0 V to 10 V (2) /
10 to 10 V (3) /
0 to 5 V (4) /
-5 to 5 V (5) /
1 to 5 V (6) /
2 to 10 V (7) /
disabled (8)
disabled
Analog Input,
4 Channels
Voltage/ Current
12 Bits
2-, 3-, or 4-Wire
EP-3124
Same as EP-3164
Same as EP-3164
Same as EP-3164
