Maintenance 3. Covers
N6 Rev.2 111
N6-A1000**
Joint #4 side cover
Arm #
3 inside cover
Arm #3 cover
Arm #1 inside cover
Joint #4 side cover
Arm #2 cover
Joint #1 cover
Joint #1 inside cover
Joint # 2 cover
Joint #2 outside cover
Joint #4 inside cover
Joint #4 outside cover
Arm #4 side cover
Arm #4 s
ide cover
Arm #4 cable cover
Base cover
Arm #
2 cover
