Maintenance 3. Covers
112 N6 Rev.2
N6-A850**R
Joint #4 side cover
Arm #3 inside cover
Arm #4 side cover
Joint #1 cover
Joint #2 outside cover
Joint #4 outside cover
Arm #4 cable cover
Arm #3 cover
Arm #1 inside cover
Base cover
Arm #2 cover
Joint #1 inside cover
Joint #4 inside cover
Arm #4 cable cover
Arm #4 side cover
Arm #2 cover
