Epson N6 Series User Manual

Maintenance 3. Covers
N6 Rev.2 113
Standard-Model (N6-A1000S*, N6-A850S*R)
Name Qty. Code, Note
Maintenance
part
Cover
(Standard
model)
Base
Base cover
1
1749181
Arm #1
(N6-A1000)
Joint # 1 cover
1
1739213
Joint # 1 inside cover
1
1739211
Arm # 1 inside cover
1
1739215
Joint # 2 outside cover
1
1739214
Joint # 2 cover
1
1739212
Arm #1
(N6-A850)
Joint # 1 cover
1
1755217
Joint # 1 inside cover
1
1755218
Arm # 1 inside cover
1
1755220
Joint # 2 outside cover
1
1755219
Arm #2
Arm # 2 cover
2
1749176
Arm #3
Arm # 3 inside cover
1
1739218
Arm # 3 cover
1
1749177
Joint # 4 side cover
2
1749178
Arm #4
Joint # 4 inside cover
1
1739223
Joint # 4 outside cover
1
1749180
Arm # 4 side cover
2
1749179
Arm # 4 cable cover
2
1739221
Tool Cross-point screwdriver (#2) 1
For cross
recessed screws
Cleanroom-Model (N6-A1000C*, N6-A850C*R)
Name Qty. Code, Note
Maintenance
part
Cover
(Cleanroom
model)
Base
Base cover
1
1761617
Arm #1
(N6-A1000)
Joint # 1 cover
1
1755506
Joint # 1 inside cover
1
1755504
Arm # 1 inside cover
1
1755508
Joint # 2 outside cover
1
1755507
Joint # 2 cover
1
1755505
Arm #1
(N6-A850)
Joint # 1 cover
1
1757779
Joint # 1 inside cover
1
1757780
Arm # 1 inside cover
1
1757782
Joint # 2 outside cover
1
1757781
Arm #2
Arm # 2 cover
2
1761612
Arm #3
Arm # 3 inside cover
1
1755511
Arm # 3 cover
1
1761613
Joint # 4 side cover
2
1761614
Arm #4
Joint # 4 inside cover
1
1755514
Joint # 4 outside cover
1
1761616
Arm # 4 side cover
2
1761615
Arm # 4 cable cover
2
1739221
Tool Cross-point screwdriver (#2) 1
For cross
recessed screws
