Maintenance 3. Covers
136 N6 Rev.2
(8)
Install the following covers.
Arm #3 inside cover
Joint #4 side cover (Arm #2 side)
Joint #4 inside cover
Details are described in the following sections:
Maintenance
3.9 Arm #3 Inside Cover
3.12 Joint #4 Inside Cover
3.11 Joint #4 Side Cover
N6-A1000**
N6-850**R
Joint #4 inside cover
Joint #4 side cover
Arm #3 inside cover
Joint #4
inside
cover
Joint #4 side cover
Arm #3
inside cover
