Epson N6 Series - Page 367

Maintenance 8. Calibration
N6 Rev.2 355
N6-A850**R
N6-A850**R
Detail of A
Joint #1
+180
deg.
-180 deg.
A
J1: +180 deg.
J1: −180 deg.
Cable direction: Arm #1 side
Joint #2
+180 deg.
-
180 deg.
A
J2: +180 deg.
J2: −180 deg.
Cable direction: Arm #2 side
