Maintenance 8. Calibration
356 N6 Rev.2
N6-A850**R
Detail of A
Joint #3
+180 deg.
-180 deg.
A
J3
: +180 deg.
J3: −180 deg.
Cable direction: Arm #2 side
Joint #4
-180 deg.
+180 deg.
A
J4: +180 deg.
J4: −180 deg.
Cable direction: Arm #3 side
